Platform Barcode Reader Scanning Desktop Laser Bar code Scanner 1D 2D QR Hands-Free Wired USB Barras
Wholesale and Drop-shipping
Welcome!
No any company information or logo in the packages.
Welcome CSV.
Contact us:Ruidida@outlook.com
Note: if you need more scanners, please contact us free time.We have stock in Brazil Warehouse. Welcome Bulk order, any question. kindly feel free to contact us.
Platform Barcode Reader Scanning Desktop Laser Bar code Scanner 1D 2D QR Hands-Free Wired USB Barras
R46S
Symbology Decode Capability
1-D:
Codabar, Code 11, Code 39, Code 93, Code 128/EAN128, EAN.UCC Composite, Interleaved 2 of 5,MSI Code, Planet, Plessey Code, Postnet, RSS, Standard 2 of 5, Telepen, UPC/EAN, etc.
2-D:
PDF417, QR code, Matrix 2 of 5, MicroPDF417, Australian Post, Canada Post, Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, TLC 39,DataMatrix, etc.
R4600S
Symbology Decode Capability
1-D: Codabar、Code 39、Code 32 Pharmaceutical (PARAF)、Interleaved 2 of 5、NEC 2 of 5、Code 93、Straight 2 of 5 Industial、Straight 2 of 5 IATA，Matrix 2 of 5，Code 11、Code 128、GS1-128、UPC-A、UPC-E、 EAN/JAN-8、EAN/JAN-13、MSI、GS1 DataBar Omnidirectional、GS1 DataBar Limited、GS1 DataBar Expanded、China Post(Hong Kong 2 of 5)、Korea Post
2-D: PDF417, QR code, MicroPDF417, Australian Post, Canada Post,Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, DataMatrix, etc.
User Environment:
1.Operating Temperature：-20°C to 60°C
2.Storage Temperature：-30°C to 70°C
3.Humidity：5% to 95% relative hum idity,non-condensing
4.Shock Specifications：Designed to withstand 1.2m(5’) drops
Ambient Light Immunity：0-100,000 Lux.
R6300
R81
Symbology Decode Capability
1D: Interleaved 2 of 5; ITF-6; ITF-14 ; ISB-128 ; Code 11; UCC/EAN-128; GS1 Databar; Industrial 2 of 5 ; Matrix 2 of 5; Code 32; Code 128 ; EAN-13; EAN-8 ; Code 39; UPC-A ; Codabar ; Standard 2 of 5 ; Plessey; MSI-Plessey; UPC-E; Code 93; GS1 composite code
2D: PDF417; Data Matrix; QR Code ; Micro PDF417; HanXin; AZTEC; Maxicode; Micro QR
Other Parameters
1. Material: ABS+TPU
2. Sensor: 480 * 640
3. Light Source: Red LED
4. Operating Temp.:0 to 50℃
5. Scanning Angle: Rotation360°, elevation±55°, deflection ± 65°
6. Resolution: Code39 ≥5mil
7.Scanning Depth
QR Code 12.50mil（7bit）：3cm - 12cm
PDF417 9.17mil（7bit）：2cm - 15cm
Data Matrix 12.50mil（8bit）：2cm - 7cm
Code 128 7.50mil（15bit）：2cm - 10cm
EAN13（10mil）：2cm - 16cm
R410
Symbology Decode Capability
1-D:
Codabar,Code 11, Code 39, Code 93, Code 128/EAN128, EAN.UCC Composite, Interleaved 2 of 5,MSI Code, Planet, Plessey Code, Postnet, RSS, Standard 2 of 5, Telepen, UPC/EAN, etc
2-D:
DOT Code, GM, PDF417, QR code, Matrix 2 of 5, MicroPDF417, Australian Post, Canada Post, Japan Post, MaxiCode, Codablock, Aztec, Dutch Post,TLC 39,DataMatrix, etc.
Other Parameters
1. Image (Pixels): 640 pixels (H)x 480 pixels (V)
2. Light Source: Red color LED
3. Interfaces Supported: USB , RS232
4. Minimum Resolution: ≥3.9 mil
5. Operating Temperature: -20°C to 60°C
6. Ambient Light Immunity: 0-100,000 Lux.
7. Decode Ranges
5 mil (code39) 0mm-60mm
13 mil (code39) 0mm-170mm
15 mil (PDF417) 0mm-60mm
13 mil (UPC-A) 0mm-150mm
30 mil (QR Code) 0mm-130mm
R4030E
Symbology Decode Capability
1-D:Codabar、Code 39、Code 32 Pharmaceutical (PARAF)、Interleaved 2 of 5、NEC 2 of 5、Code 93、Straight 2 of 5 Industrial、Straight 2 of 5 IATA，Matrix 2 of 5，Code 11、Code 128、GS1-128、UPC-A、UPC-E、 EAN/JAN-8、EAN/JAN-13、MSI、GS1 DataBar Omnidirectional、GS1 DataBar Limited、GS1 DataBar Expanded、China Post(Hong Kong 2 of 5)、Korea Post.
2-D:DOT Code, Codeblock A、Codeblock F、PDF417、Micro PDF417、GS1 Composite Codes、QR Code、 Data Matrix、MaxiCode、Aztec、HANXIN.
