F701 RC Receiver PPM 2.4GHz 7CH DSMX DSM2 Spread Better Than Spektrum AR7000 For DX7 DX8 JR Transmitter for Helicopter

DSMX PPM RC Receiver Receptor Acceptor AR7000 MK710 2.4GHz 7CH RX Support SPEKTRUM DX6i DX7 DX8 JR DSX7 DSX9 for RC Quadcopter

Features:
For FSFLY Series receiver uses good technology, compatible with For Spektrum and JR remote control system, including JR12X, 11X, X9503, X9303, SpektrumDX10t, DX8, DX7s, DX7se, DX6i,
DX5e etc., with built-in19db amplifier and 2db antenna, the device has a good quality and stable signals even in long distance.
Separate outputs PPM
With external small satellite.

Specifications:
Channel (ch): 7ch
Operating Voltage (V): 4.8V-8.4V
Air distance (M): 1500M + / full
Dimensions (mm): 46 * 24 * 14mm/ 1.8 x 0.9 x 0.6 inch
Delivery size: 128 x 89mm/ 5 x 3.5 inch
Weight: 12g
Package weight: 13g

Matching(Code)
a: Insert the code strip to the BIND jack of the receiver;
b: switch on the power supply to the receiver
c: Press and hold the switch on the transmitter
d: Observe the LED on the receiver, if find that the LED is flash to Always, that means successful Matched.
e: Take out the code strip.

Package includes:
1 x F701 Receiver

1x Bind Plug
