Ultra 5.8G Long Range VTX 3W 25mW/400mW/800mW/1500mW/3000mW/Pit mode FPV Transmitter for Frame Camera Kit

Specification:

Model: Ultra3000 VTX 4.9G-5.8G 3W

Input voltage: DC 7-36V(2-8S Battery)

Output: 5V@600mA(Power 5V to camera)

Input impedance: 75Ω

Protocol: IRC Tramp

Shell material: Aluminum alloy

Heat dissipation mode：Active cooling

Fan specifications：20mm*20mm*6.5,12000rpm

Antenna connector: MMCX connector

Cable connector: GH1.25-6P connector

Output power: 25mW/400mW/800mW/1500mW/3000mW/Pit mode

Frequency tables: 56 CH

Video format: PAL / NTSC

Microphone: Built in microphone

Size: 37mmx29mmx15mm

Weight: 23g(without cable)

Mounting holes: 20mmX20mm(M2)

1. 3W super-power ,suitable for Long Range flight with good stability.

2. Six power levels: 25mW/400mW/800mW/1500mW/3000mW/Pit mode .

3. Two-layer board cooling structure,separate power BEC and main-board,reducing

and shielding from the insinal interference.

4. Temperature control protection function that can prevent high temperature

burning.

5. Selected high strength aluminum alloy CNC housing, auxiliary cooling

6. Built-in micro-turbine fan active cooling, rotating speed of 12000 rpm

7. Wide voltage input, supports 7V-36V voltage input.

8. VTX control protocol is IRC Tramp,supports OSD parameter adjustment.

9. VTX built in microphone,real-time return of Drone's sounds.

10. Has 3 regional frequency tables to meet the needs of various regions.

11. One function buttons, three indicator lights, easy to operate.

12. Mounting holes is 20mmx20mm.

Support IRC Tramp Protocol

Ultra3000 VTX supports the IRC TRAMP protocol and the modification of

video transmission parameters through the remote control, including

frequency, working power and so on.

NOTE: For BetaFlight flight controller firmware above BetaFlight 4.1.0,you need

upload a VTX Table to the flight controller before using the remote control to

modify the video transmitter parameters normally.

ULTRA3000_VTX_3W.json

For the use of the video transmitter table, please refer to this article

“How to Setup Betaflight VTX Table – SmartAudio Tramp VTX Control"

1 x Ultra3000 VTX 3W

1 x MMCX connector to SMA connector 82cm

1 x GH 1.25-6P connector cables 150mm

1 X 5.8G or 4.9G antenna (send as your choice)
